Component Database:
Glass Expansion - Ceramic VeeSpray nebulizer
| |
|
|
| |
|
| |
|
| Year of introduction |
|
| Status |
available |
| Company |
Glass Expansion
|
| Categories |
Sample introduction: Nebulizers
|
|
Ceramic VeeSpray - handles high particle and TDS loads best
The Ceramic VeeSpray nebulizer is made from alumina ceramic, making it ideal for HF analyses. It provides reproducible performance when working with samples containing large particulates. It has the same 6mm diameter as the standard concentric and the Alumina material makes it the most robust and abrasion resistant ICP nebulizer. - Material: 99.8% Alumina Ceramic
- High physical reproducibility ~ 1%
- TDS tolerance, typically up to 30%
- High tolerance to particulates, typically up to 300um
- Must be pumped - does not self aspirate
- Design uptake range: 0.6 - 3ml/min. Operates best between 1.5 - 2.5ml/min
|
| Specifications |
|
All Ceramic VeeSpray nebulizers are supplied with:
750mm length of STT-16-75 sample tubing (sample tube 0.75mm ID x 1.6mm OD)
Two ratchet connectors 2361 and ferrules 70-803-0780
EzyLok connector QSM-4 and tube adaptor 70-803-0697
|
