Instrument Database:
Shimadzu Europe - GC-8A Gas Chromatograph
| |
|
|
| |
|
| |
|
| Year of introduction |
|
| Status |
historical ( out of sale ) |
| Company |
Shimadzu Europe
|
| Categories |
Chromatography: GC
|
The reliable and compact GC-8A is Shimadzu's basic gas chromatograph model for dedicated applications. Economical and simple to use, the GC-8A supports a single detector, manual pressure or flow control, on column injection port(s), and analog output. Isothermal or single temperature ramp program models are available. The GC-8A is only 17.3 inches (43.9 cm) wide, yet its large oven facilitates simple column installation and maintenance.
Detectors available:
- FID (Flame Ionization Detector)
- TCD (Thermal Conductivity Detector)
- ECD (Electron Capture Detector)
- FPD (Flame Photometric Detector)
|
| Specifications |
|
Models available
Isothermal with TCD
Temperature program with TCD
Isothermal with FID
Temperature program with FID
Isothermal with ECD
Temperature program with FPD
Column oven temperature (isothermal models)
Temperature range: Ambient À 399°C (1o increments)
Temperature control: Proportional integration type
Temperature control accuracy:
ß0.1oC
Heating speed: Ambient to 350°C in 13 minutes
Cooling speed: 350°C to 100°C in 3.5 minutes
Column oven temperature (temperature program models)
Temperature range: -100°C À 400°C (cryogenic accessories required for sub-ambient temp. operation)
Temperature control: Proportional integration type
Temperature control accuracy:
ß0.1 oC
Heating speed: Ambient to 350°C in 13 minutes
Cooling speed: 350°C to 100°C in 3.5 minutes
Temperature program
(temperature program models)
Initial temperature: -100°C À 399oC (1o increments)
Final temperature: 0°C À 400°C (10o increments)
Program rate: 0.5,1,2,3,4,5,6,8,10,16,20,32°C/min
Overheat protection
Two stage protection:
- If the temp. exceeds the set temp. by 30°C, the heater is automatically turned off
- If the temperature exceeds 420°C, the heater is automatically turned off
Injection port/detector temperature
Temperature range: Ambient À 400oC (10oincrements)
Ambient À 350°C (ECD model)
Temperature control: Proportional integration type
Temperature control accuracy:
ß0.1 °C
Overheat protection: yes
Temperature control
(isothermal models)
The column oven, injection port/detector, auxiliary temperatures are selectively indicated; when temperatures have reached the set point, READY is indicated.
Temperature control
(temperature program models)
The column oven, injection port/detector, auxiliary temperatures are selectively indicated, with pushbutton selection
Columns
Stainless steel: 6 m x 2
Stainless steel (FPD, ECD models): 12 m x 1
Glass: 5.4 m x 2
Glass (FPD, ECD models): 5.4 m x 1
Capillary (with option): 100 m x 1
Capillary (ECD model, with option): 100 m x 1
Injection port
Two on-column injection ports
FPD, ECD models: One on-column injection port
Flow control: carrier gas
(isothermal models)
TCD, FID models: Two pressure regulators and two column inlet pressure gauges.
Flow control: carrier gas
(isothermal models)
ECD model: One pressure regulator and one column inlet pressure gauge
Flow control: carrier gas
(temperature program models)
TCD, FID models: One primary pressure indicator, one primary pressure gauge, two differential flow controllers, and two column inlet pressure gauges
Flow control: carrier gas
(temperature program models)
FPD model: One primary pressure regulator, one primary pressure gauge, one differential flow controller, and one column inlet pressure gauge
Flow control: Hydrogen
FID models: Two pressure regulators and two column inlet pressure gauges
Flow control: Air
FID models: One pressure regulator and one pressure gauge
Dimensions (mm) and Weight (kg) (isothermal models)
TCD model: 440W x 405D x 435H, 26.5
FID model: 440W x 405D x 570H, 34.5
ECD model: 440W x 405D x 435H, 26.0
Dimensions (mm) and Weight (kg) (temperature program models)
TCD model: 440W x 405D x 625H, 36.0
FID model: 440W x 405D x 625H, 34.5
FPD model: 440W x 405D x 785H, 35.0
Power requirements
AC 100/115V or 200/220V as ordered, 1500VA max., 50/60 Hz
|
